‘V’ type tilted body, made of high strength wear-resistant steel plate, with high wear and impact resistance. The optimized body structure guarantees smooth dumping without materials stuck; standard body: welded from 16mm bottom plate, 10mm side plate, and 8mm front plate;

The front and rear suspension of the truck is provided with the oil-gas (nitrogen) suspension cylinder characteristic of variable damping, featuring good damping effect and maintainability; thus, the road impact can be well absorbed; even in the extreme environment, the driver can still enjoy comfort during operation. Front suspension travel: 200mm(7.9 in)；Middle and rear suspension travel: 155mm(6.1in.

Having been carefully analyzed, calculated and designed, the frame is made of high strength steel plates, of box type construction, and features light weight, good impact resistance, high bending and torsional resistance, and good durability.Casting structure can preferentially reduce stress concentration and extend the service life.

FC mining special electronic automatic transmission is adopted to realize 6 forward gears and 1 reverse gear. This type of transmission can realize automatic speed change according to the load.The integration of hydraulic torque converter and hydraulic retarder is selected to provide the truck with the hydraulic retarding function.

The cab is FOPS/ROPS certified. Equipped with integral four-pillar tipping protection design, adjustable cushioned seat, luxury upholstery, and tiltable and telescopic steering wheel to provide a comfortable operating space.
